Dual IP Bullet Safire Thermal Camera - 256x192 VOx | 3.1mm Lens - Optical sensor 1/2.7” 4 MP | Lens 4mm - Thermal sensitivity ≤ 40mK - Fire detection and alarm - Temperature measurement range -20~150ºC / ± 8ºC
  • Brand: Safire
  • Product Code: SF-IPTD012DA-3D4-256
  • Availability: Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

Dual IP Bullet Safire Thermal Camera - 256x192 VOx | 3.1mm Lens - Optical sensor 1/2.7” 4 MP | Lens 4mm - Thermal sensitivity ≤ 40mK - Fire detection and alarm - Temperature measurement range -20~150ºC / ± 8ºC


  • Safire
  • Thermal Turret Dual IP Camera
  • Thermal sensor 256x192 Vox
  • Lens 3.1 mm (thermal)
  • Temperature measurement range -20º C~150º C (±8ºC)
  • Thermal sensitivity < 40mK
  • Optical sensor 1/2.7” Progressive CMOS
  • 4 Megapixel (2688x1520)
  • Lens 4 mm (optical)
  • Colour 0.0176 Lux / B&W 0.0035 Lux
  • WDR
  • IR Range 15m
  • H.265 / H.264 -RJ-45 10/100 BaseT
  • PoE IEEE802.3af
  • Audio
  • Alarms
  • Preventive fire detection and alarm
  • SD card recording
  • WEB interface, Safire Control Center, Smartphone and NVR
  • ONVIF Compatible
  • Weatherproof IP66



  • Safire Thermal IP Camera
  • Installation material
  • User instructions
  • Junction box included

alt


Article
Brand Safire
Product Code SF-IPTD012DA-3D4-256
General
Internal storage Micro SD card up to 256GB
Thermal sensor 256x192 Vanadium Oxide
Optical sensor 1/2.7” Progressive Scan CMOS 4 Megapixel
Power 12VDC, 0.5A, max.6W; PoE IEEE802.3af, 0.14~0.22A, max.6.5W
Range performance Human: 150 (Detection) / 38 (Recognition) / 19 (Identification) m Vehicle: 460 (Detection) / 112 (Recognition) / 56 (Identification) m
Main Stream Rate 1280 × 720, 704 × 576, 640 × 512, 320 × 240 (1~25FPS) Thermal 2688 × 1520, 1920 × 1080, 1280 × 720) (1~25FPS) Optical
Extra Stream rate 704 × 576, 640 × 512, 320 × 240 (1~25FPS) Thermal 704 x 576, 352 x 288 (1~25FPS) Optical
Network Interface Ethernet 10/100 BaseT
Remote Access WEB, CMS (DSS/PSS), Smartphone and NVR interface
Interoperability ONVIF
Weight 940 g
VCA ranges Human: 28.4m Vehicle: 75.6 m Tº measurement (0.2x0.2m): 11.7 m Tº measurement (1x1m): 58.3 m
Lens 3.1 mm (Therm) / 4 mm (Opt)
Audio 1/ 1 line level 600 ohm
Thermal sensitivity < 40mK (0.05 º C)
Thermal measurement range -20 ~150 º C / ± 8 º C
Viewing angle 50°×37.3° (Term) / 84° × 43.1° (Opt)
Spectral range 8~14μm
Pitch detector 12μm
Temp. operation -40º C ~ +65º C
VCA Up to 8 VCA rules (linecrossing, intrusion, entry and exit of area)
Temperature rules Up to 21 rules (10 points, 10 areas and 1 line)
Dimensions 138.3 mm (D) x 138.3 (W) x 123.1 (H) mm
Alarm 1/1 Relay
Degree of protection Weatherproof IP66
Compression H.265 / H.264 / MJPEG
