Camera
Day/Night Mode	Day/Night/Auto/Customize/Schedule
Digital Zoom	16X
Image Sensor	1/2.8″ Progressive Scan CMOS
S/N	>55dB
Shutter Time	1/100000s~1s
WDR	120dB Super WDR
Min. Illumination	Color: 0.008Lux@F1.6 B/W: 0Lux with IR on
IR Distance	Up to 140m
Lens
Aperture	F1.6~F2.8
Field of View	H57°~H4°/D69°~D5°/V44°~V1°
Focus Control	Auto/Semi-Auto/Manual
Iris Control	Auto
Minimum Working Distance	1000/1500mm (Wide/Tele)
Zoom Speed	Approx 4s (Wide-Tele)
Focal Length	5.3~64mm, 12X Optical Zoom
Video
Image Setting	Brightness/Contrast/Saturation/Sharpness
Max. Image Resolution	2592x1944
Primary Stream	60Hz: 30fps@(2592x1944, 2592x1520), 45fps@(2048x1536), 60fps@(1920x1080, 1280x960, 1280x720) 50Hz: 25fps@(2592x1944, 2592x1520), 45fps@(2048x1536), 50fps@(1920x1080, 1280x960, 1280x720)
ROI	Up to 8 areas
Secondary Stream	60Hz: 30fps@(704x576, 640x480, 640x360, 352x288, 320x240) 50Hz: 25fps@(704x576, 640x480, 640x360, 352x288, 320x240)
Tertiary Stream	60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240) 50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
Video Bit Rate	16Kbps~16Mbps(CBR/VBR Adjustable)
Video Compression	H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Privacy Masking	Up to 8 Areas (Mask Area and Mosaic Area are optional)
Network
Protocol	IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
Network Storage	NAS(Support NFS, SMB/CIFS), ANR
Interface
Alarm I/O	1/1 (Optional)
Audio I/O	1/1 (Optional)
Ethernet	1*RJ45 10M/100M Ethernet Port
Intelligent Analytics
Face Detection&Face Attribute Recognition	Detect and capture faces, get real-time snapshots; The attributes include Age, Gender, Glasses, Mask and Cap; Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically.
Object Counting & Report	Count the number of objects crossing the line, optionally human and vehicle, Support regional people counting for up to 4 detection areas
Video Analysis	Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed
Audio
Two-way Audio	Support
Audio compression	G.711/AAC/G.722/G.726
Audio Sampling Rate	8/16/32/44.1/48KHz
Audio Bit Rate	16~256kbps
System
Advanced Function	BLC, HLC, 2D DNR, 3D DNR,Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
Event Action	FTP Upload, SMTP Upload, SD Card Record, External Output (Optional), SIP Phone, White LED, PTZ Motion, HTTP Notification, etc.
Event Trigger	Motion Detection, Network Disconnection, External Input (Optional), Audio Alarm (Optional), etc.
SIP/VoIP Support	Yes, Voice & Video-over-IP
Storage	Support microSD/SDHC/SDXC Card Local Storage, up to 1TB
System Compatibility	ONVIF Profile G & M & S & T, API
General
Dimensions	160mmX273.5mmX210mm (Wall Mount) / 218mmX120mmX172mm (Pedestal Mount)
Power Consumption	14W MAX / 20W MAX (With IR on)
Weather Proof	Up to IP66-rated for Weather-resistant Performance
Working Temperature	-40℃~60℃
Power Supply	PoE (802.3at) / DC 12V/2A±10%
Weight	2Kg (Wall Mount) / 1.8Kg (Pedestal Mount)
Working Humidity	0~95%(Non-condensing)
PTZ
Auto Tracking	Support
Other Function	Auto Scan, Auto Home, Preset Freezing, 3D Positioning, PTZ Limits, Initial Position
Pan Range/Pan Speed	360°endless / Pan Manual Speed: 0.1°~50°/s, Pan Preset Speed: 50°/s
Patrol	8 Patrols, up to 48 presets each patrol
Pattern	4 Patterns
Power Off Memory	Support
Preset Quantity	300
Proportional Zoom	Support
Tilt Range/Tilt Speed	-45°~30° / Tilt Manual Speed: 0.1°~25°/s, Tilt Preset Speed: 25°/s
