DVR 5n1 X-Security - 8 CH HDTVI/HDCVI/AHD/CVBS (4K) + 8 IP (8Mpx) - Audio over coaxiaal - 2 SATA-poorten tot 16TB - 2 CH gezichtsherkenning - 8 CH Mens- en voertuigherkenning
  • Merk: X-Security
  • Productcode: XS-XVR6208S-4KL-2AI
  • Levertijd: Niet meer leverbaar
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

DVR 5n1 X-Security - 8 CH HDTVI/HDCVI/AHD/CVBS (4K) + 8 IP (8Mpx) - Audio over coaxiaal - 2 SATA-poorten tot 16TB - 2 CH gezichtsherkenning - 8 CH Mens- en voertuigherkenning


  • X-Security
  • DVR 5n1
  • 8-kanaals video HDTVI/HDCVI/AHD/CVBS / 8+8 IP / 8-kanaals audio
  • H.265+/H.265/H.264+/H.264
  • Resolutie 4K (7FPS) of 6Mpx (10FPS) of 5Mpx (12FPS) 4K-N, of 4MP/3MP (15FPS) 4M-N/1080P/720P/960H/D1/CIF of (25/30FPS) [%VAR%] [%VAR%]
  • PTZ-besturing (RS485/coaxiaal)
  • Audio over coaxiaal
  • HDMI Full HD, VGA & CVBS-uitgangen
  • 2 CH vergelijking van gezicht
  • Herkenning van mens en voertuig (beschikbaar voor 8 CH coaxiale video)
  • Muis
  • 2 USB-poorten
  • Ruimte voor 2 HDD's
  • Compacte maat


  • DVR 5 in 1 X-Security
  • Mouse
  • Adapter AC/DC 12 V / 1.5 A

alt




Article
Brand X-Security
Product Code XS-XVR6208S-4KL-2AI
General
Internal storage 2 SATA HDD 3.5" of up to 16 TB (not included)
Power DC 12V / 2A
Coding All channel: 4K(1 fps–7 6MP(1 fps–10 fps); 5MP(1 fps–12 4K-N, fps); 4MP/3MP(1 fps–15 4M-N/1080P/720P/960H/D1/CIF (1 fps–25/30 fps)
Dual-Stream encoding 960H (1 fps–15 fps); D1/CIF(1 fps–25/30 fps)
Video format HDTVI / HDCVI / AHD / CVBS / IP
Hybrid configuration Up to 16 IP Channels (8Mpx), replacing all the BNC channels
Recording method Manual, programmed, motion detection, alarm
Remote Access Web browser (ActiveX), mobile phone application or PSS software
Video inputs 8 Channels BNC (HDTVI / HDCVI / AHD / CVBS)
Communication RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet)
Video outputs 1 HDMI Full HD, 1 VGA
Audio Inputs 8 BNC, 1 RCA channels
Display Resolution HDMI: 4K, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720
Video / audio compression H.265+/H.265/H.264+/H.264
Audio Outputs 1 Channel RCA
Total bandwidth 128 Mbps
Bidirectional audio Reusing the audio input/output
Intelligent motion detection Up to 8 channels capable of classifying targets amongst humans and vehicles
Alarms No
video analysis IVS: Tripwire | Area intrusion | Abandoned object | Face detection IP Mode, Face Recognition and IVS cannot be enabled at the same time
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Dimensions / Weight 53 (H) x 375 (W) x 289 (D) mm / 1.59 Kg
Facial recognition Up to 2 analog channels for live face comparison
Backup USB / Network
