X-Security Dual IP thermische camera - 256x192 VOx | 7 mm lens - optische sensor 1/2,7” 4 MP | Lens 8 mm - Thermische gevoeligheid ≤50mK - Branddetectie en alarm - Instelbaar niveau van optische/thermische beeldfusie
  • Merk: X-Security
  • Productcode: XS-IPTD989A-7D4-AI
  • Levertijd: Niet meer leverbaar
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

X-Security Dual IP thermische camera - 256x192 VOx | 7 mm lens - optische sensor 1/2,7” 4 MP | Lens 8 mm - Thermische gevoeligheid ≤50mK - Branddetectie en alarm - Instelbaar niveau van optische/thermische beeldfusie


  • X-Security
  • Dubbele thermische IP-camera
  • Thermische sensor 256x192 VOx
  • Optische sensor 4Mpx 1/2,7” Progressive Scan CMOS
  • Lens 7 mm (Therm) / 8 mm (Opt)
  • 18 kleuren
  • Thermische gevoeligheid < 50mK (0,05ºC)
  • H.265 / H.264 / MJPEG
  • RJ-45 10/100 BaseT
  • PoE IEEE802.3at
  • Weerbestendig IP67
  • Audio en alarmen
  • IVS-regels
  • Branddetectie en alarm
  • Opname op SD-kaart
  • WEB-, CMS (DSS/PSS), smartphone- en NVR-interface
  • ONVIF-compatibel


  • X-Security IP thermal camera
  • Installation material
  • User instructions
Article
Brand X-Security
Product Code XS-IPTD989A-7D4-AI
General
Internal storage Micro SD card up to 256GB
Thermal sensor 256x190 Vanadium oxide
Optical sensor 1/2.7” Progressive Scan CMOS 4 Megapixel
Main Stream rate Term: 1280 × 960 (1.3M), XVGA (1024 × 768), VGA (640 × 480), 256 × 192 × [%VAR%] Opt: 2336 × 1752, 1080P (1920 × 1080), 720P (1280 × 720), D1 (704 × 576)
Extra Stream rate Term: VGA (640 × 480), 256 × 192, 256 × 192 Opt: 720P (1280 × 720), D1 (704 × 576)/CIF (352 × 288), 352 × 288
Remote Access WEB, CMS (DSS/PSS), Smartphone and NVR interface
Interoperability ONVIF
Spectral range 8~14μm
Weight < 850 g
Lens 7 mm (Therm) / 8 mm (Opt)
Audio 1 input / 1 output
Dimensions 122.5 (D) x 107 (H) x 122.5 (W) mm
Power 12VDC 6.5W (LED OFF) / 13W (LED ON, HEATER ON) , PoE IEEE802.3at
Viewing angle 24°×18° (Term) / 33.4°×25° (Opt)
Intelligent functions Detection of fire and alarm, line crossing, intrusion
Temperature Measurement No
Pitch detector 12μm
Temp. operation -30º C ~ +60º C
Thermal sensitivity < 50mK (0.05 º C)
VCA IVS rules (cross line, intrusion, area entry and exit)
Rules for fire Up to 4 regions of fire detection
smart improvements DWDR, 3DNR, BLC, HLC AGC, ROI, Privacy Mask
Alarm 1 input / 1 output
Degree of protection Weatherproof IP67
Network interface Ethernet 10/100M BaseT
Compression H.265 / H.264 / MJPEG
