Nearity for videoconferencing - Resolution 2160p 4K UHD - 120° Viewing angle - 5 Built-in microphones 180° - Omnidirectional speaker - Plug & Play
  • Brand: Nearity
  • Product Code: AW-C30R
  • Availability: Discontinued
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

Nearity for videoconferencing - Resolution 2160p 4K UHD - 120° Viewing angle - 5 Built-in microphones 180° - Omnidirectional speaker - Plug & Play


Video conferencing device with 2160p, 4K, UHD resolution, 5 microphone array and omni-directional speakerphone, with chaining capability via Ethernet cable. up to 4 AW-A20 (speaker + microphones, not included) powering only the AW-C30R.

Designed specifically for use in video conferencing from small to medium sized rooms up to 18 people. It has a resolution of 8 Megapixels at 30 fps in format 16:9 and a wide-angle viewing angle greater than the 120º. As for the integrated two-way audio, it includes a 5 microphone array that picks up speech clearly up to 5 meters in any direction with real-time noise and echo cancellation and an adjustable omnidirectional speaker.

It includes a stand for desktop installation. The power is supplied discreetly from the bottom of the device with the DC48V adapter included. Communication with the PC is via USB C (USB C angled cable to USB A of 5 meters included). Plug & Play, no plug-in or accessories needed. Can be integrated on Windows PC, Mac or Linux and is compatible with the main video platforms (Zoom, Microsoft Teams, Skype, Google Meet, Webex, etc).



  • Device
  • 48VDC Power supply
  • USB C to USB A angled cable 5 metres
  • Table stand
  • Quick Start Guide

alt


Article
Brand Nearity
Product Code AW-C30R
General
Manufacturer no A30R
Coding Resolution 2160p 4K UHD (3840x2160) / 30 FPS
Maximum resolution 8 Megapixel (3840x2160)
Microphones 4 Ω / 5 W Measured output power 160 Hz ~ 20 KHz Response Frequency 80 ± 3 dB Volume (800, 1000, 1200, 15000 Hz) @ 1 W / 1 m
Sensor Sony 1/2.8" CMOS f/1.8
Weight 2033 g
Communication USB 2.0 Type C (cable 5 m to USB Type A included) / Plug & Play
Audio Array of 5 microphones 180° and omnidirectional speaker with echo cancellation
Dimensions 81(H)*77(D)*570(W)mm
FOV Horizontal 110º, Vertical 75º, Diagonal 120º
Speaker -38 dBV/Pa 94 dB SPL @ 1 kHz Voice pickup up to 5 meters from device
Power DC 12V via USB connection, consumption 1.35 A
Image improvements 3D-NR, Anti-Flickering
Use Interior
Compression MJPEG / H264
