ThermTec Dual IP Thermal Camera - 384x288 VOx | 35mm Lens - Pixel pitch 12μm - Thermal sensitivity ≤35mK - Optical sensor 1/2.8” 4 Mpx - Temperature measurement
  • Brand: ThermTec
  • Product Code: THERMTEC-HM335
  • Availability: In Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

ThermTec Dual IP Thermal Camera - 384x288 VOx | 35mm Lens - Pixel pitch 12μm - Thermal sensitivity ≤35mK - Optical sensor 1/2.8” 4 Mpx - Temperature measurement


  • ThermTec
  • Dual Thermal IP Camera
  • Thermal sensor 384x288 VOx
  • Optical sensor 1/2.8” Progressive Scan CMOS 4Mpx
  • Lens 35 mm (Therm) / 16 mm (Opt)
  • Range IR30m
  • Thermal sensitivity ≤35mK (0.05 º C)
  • Pixel Pitch 12μm
  • Temperature measurement
  • H.265/H.264
  • RJ-45 10/100M BaseT
  • PoE+ IEEE802.3at
  • Alarms
  • Local recording due to network error
  • WEB, CMS, Smartphone and NVR interface
  • ONVIF Compatible
  • Weatherproof IP66



  • ThermTec Dual IP Thermal Camera
  • Installation material
  • User instructions
  • Junction box
  • Power supply 12V DC

alt


Article
Brand Thermtec
Product Code THERMTEC-HM335
General
Internal storage EMMC up to 16GB
Thermal sensor 384x288 Vanadium oxide
Optical sensor 1/2.8” Progressive Scan CMOS 4 Megapixel
Thermal focus Motorized
Main Stream rate Term: 768x576 / 640x480 / 384x288 (25fps) Opt: 2592x1536 / 1920x1080 / 1280x720 ​(25fps)
Extra Stream rate Term: 640x480 / 352x288 / 384x288 (25fps) Opt: 1280x720 / 768x576 / 640x480 / 384x288 (25fps)
Remote Access WEB Interface, Safire Control Center, Safire Connect and NVR
Interoperability ONVIF
Spectral range 8~14μm
Weight 1800 g
Image enhancements DWDR, 3DNR, BLC, HLC AGC, ROI, Privacy Mask
Image Fusion Supported
Lens 35 mm (Therm) / 16 mm (Opt)
Audio No
Dimensions 376 (D) x 142.82 (W) x 102.78 (H) mm
Power 12VDC, max.5 W / PoE+ (802.3at) 1-OUT, up to 15W
Thermal viewing angle 7.5°×5.7° (Therm)
Pitch detector 12μm
Temp. operation -20º C ~ +60º C
Thermal sensitivity < 35mK (0.05 º C)
Alarms 1 IN / 1 OUT
Thermal measurement range -20 ~150 º C / ± 8 º C
VCA Up to 10 VCA rules (motion detection, line crossing, intrusion, area entry and exit)
Advanced features Fire and smoke detection Protection against direct sunlight
Fire Detection Dynamic detection, up to 10 points
Degree of protection Weatherproof IP66
Network interface Ethernet 10/100M BaseT
Compression H.265 / H.264
