X-Security NVR 32CH 16CH PoE AI Recorder | Maximum resolution 12 Megapixel | 32CH IP /16 PoE | AI smart features | 4 HDD up to 16TB per disk | WEB, DSS/PSS, Smartphone and NVR
  • Brand: X-Security
  • Product Code: XS-NVR6432A-4K-16P-4AI
  • Availability: In Stock
Om te bestellen en prijzen te kunnen zien moet u zich registreren of inloggen.
To order and view prices you must register or login.

X-Security NVR 32CH 16CH PoE AI Recorder | Maximum resolution 12 Megapixel | 32CH IP /16 PoE | AI smart features | 4 HDD up to 16TB per disk | WEB, DSS/PSS, Smartphone and NVR


  • X-Security
  • Face Recognition NVR Recorder
  • 32CH
  • 16 CH POE
  • Bandwidth max 384 Mbps
  • WIZSENSE technology Maximum resolution 12 Megapixel
  • Smart H.265/Smart H.264 Compression
  • Face recognition and detection
  • Perimeter Protection
  • ANPR by camera
  • SMD Plus
  • Video Metadata
  • Heat map by camera
  • people counting
  • Unknown face alarm
  • Search by face
  • Database of up to 100,000 faces
  • 2 VGA and 2 HDMI 4K
  • Mouse
  • Space for 4 HDDs
  • alarms
  • Audio
  • WEB interface, CMS (DSS/PSS), Smartphone and NVR
  • ONVIF-compliant


  • X-SECURITY NVR
  • Mouse
  • Power supply cable
  • User instructions

alt


Article
Brand X-SECURITY
General
Internal storage 4 SATA HDDs up to 16TB (not included)
Inputs for IP cameras 32 channels / 16 POE channels
Supported IP cameras X-SECURITY (proprietary protocol), ONVIF
Power AC 100~240V 50~60 Hz
Artificial intelligence Facial recognition up to 16Ch, perimeter protection up to 4Ch and SMD plus up to 8CH
Resolution 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
Recording method Manual, scheduled, motion detection, alarm
Remote Access Browser (ActiveX), Mobile phone app or PSS software
Two-way Audio 1 input, 2 output, RCA
Weight 4.74 Kg
Communication 3xUSB (Mouse and backup) / 2 RJ45 10/100/1000M (Ethernet)
Installation Rack or Desktop
Video compression format Smart H.265+ / H.265 / Smart H.264+/ H.264
Video outputs 2 HDMI, 2VGA
Bandwidth 384 Mbps
Decoding capacity 2-ch 32 MP@20 fps; 2-ch 24 MP@20 fps; 4-ch 16 MP@30 fps; 5-ch 12 MP@30 fps; 8-ch 8 MP@30 fps; 12-ch 5 MP@30 fps; 16-ch 4 MP@30 fps; 32-ch 1080p@30 fps AI enabled: 1-ch 32 MP@20 fps; 1-ch 24 MP@20 fps; 2-ch 16 MP@30 fps; 4-ch 12 MP@30 fps; 4-ch 8 MP@30 fps; 8-ch 5 MP@30 fps; 12-ch 4 MP@30 fps; 24-ch 1080p@30 fps
Dimensions 70 (H) x 440 (W) x 415.1 (D) mm
Simultaneous multifunction Pentaplex: Direct, Recording, Playback, Backup and Remote Access
Alarm 16 Inputs / 6 Relays
Backup USB (Memory, HDD, CD-RW, DVD-RW) / Network / SARA
